13636661571
Fw |
72 mm |
D |
90 mm |
Cr |
108000 N |
Cor |
198000 N |
Cur |
34500 N |
Reference speed |
3650 rpm |
Limiting speed |
6300 rpm |
rmin |
1 mm | Minimum chamfer size |
C |
45 mm | Outer ring width |
Tmin |
-30 °C | Minimum operating temperature |
Tmax |
120 °C | Maximum operating temperature |
