d |
325 mm |
D |
450 mm |
B |
60 mm |
Ca |
172000 N |
Coa |
1110000 N |
Cua |
N |
H1 |
40 mm | Outer ring contact surface height |
J |
342 mm | Inner ring fixing hole diameter |
|
|
0.2 mm | Height contact face outerring H1 upper tolerance |
J1 |
430 mm | outer ring fixing hole diameter |
d1 |
9.3 mm | Inner ring fixed aperture |
|
|
-0.2 mm | Height contact face outerring H1 lower tolerance |
d2 |
15 mm | Fixed hole counterbore diameter |
D1 |
415 mm | Outer diameter D1 |
a |
8.2 mm | Fixed hole counterbore depth |
D2 |
380 mm | Inner ring rib diameter |
D3 |
413 mm | Outer diameter D3 |
|
|
34 | Number of inner ring fixing holes |
t1 |
6 µm | Axial and radial runout, measurement standard; Measured on mounted bearing, with ideal adjacent construction. |
d3 |
9.3 mm | Outer ring fixed aperture |
|
|
33 | Number of outer ring fixing holes |
n |
36 | pitch |
t |
10 ° | Pitch circle separation angle |
G |
M12 | Threaded extraction hole |
|
|
3 | Number of threaded extraction holes |
MA |
34 Nm | Tightening torque |
|
|
2 | Number of fixing screws |
T min |
-30 °C | Minimum operating temperature |
T max |
120 °C | Maximum operating temperature |
