13636661571
d |
76.2 mm |
D |
145.79 mm |
B |
15.87 mm |
Di |
111.8 mm | Inner diameter outer ring |
La |
133.1 mm | Pitch diameter fixing hole outer ring |
na |
8 | Number of outer ring fixing holes |
hi |
13 mm | single ring height |
dB |
6.9 mm | fixing hole |
dS |
11 mm | diameter of fixing hole |
tS |
6.35 mm | fixing hole depth |
Li |
88.9 mm | Pitch circle diameter fixing hole inner ring |
ni |
8 | Number of inner ring fixing holes |
VSP min |
0.005 mm | Minimum bearing preload |
VSP max |
0.02 mm | Maximum bearing preload |
T min |
-30 °C | Minimum operating temperature |
T max |
80 °C | Maximum operating temperature |
Ca |
31,500 N | Basic dynamic load rating, axial |
Cr |
22,500 N | Basic dynamic load rating, radial (for radial load only) |
C0a |
57,000 N | Basic static load rating, axial |
C0r |
28,000 N | Basic static load rating, radial (for radial load only) |
Fr zu. |
7,600 N | Max. radial load screws |
