13636661571
d |
380 mm |
D |
480 mm |
B |
26 mm |
Di |
430.6 mm | Inner diameter outer ring |
La |
462 mm | Pitch diameter fixing hole outer ring |
na |
20 | Number of outer ring fixing holes |
da |
429.4 mm | Outer diameter |
hi |
26 mm | single ring height |
dB |
9 mm | fixing hole |
dS |
15 mm | diameter of fixing hole |
tS |
9 mm | fixing hole depth |
Li |
398 mm | Pitch circle diameter fixing hole inner ring |
ni |
20 | Number of inner ring fixing holes,M10Tread fixing hole |
VSP min |
0 mm | Minimum bearing preload |
VSP max |
0.02 mm | Maximum bearing preload |
T min |
-30 °C | Minimum operating temperature |
T max |
80 °C | Maximum operating temperature |
Ca |
96,000 N | Basic dynamic load rating, axial |
Cr |
68,000 N | Basic dynamic load rating, radial (for radial load only) |
C0a |
345,000 N | Basic static load rating, axial |
C0r |
168,000 N | Basic static load rating, radial (for radial load only) |
Fr zu. |
50,000 N | Max. radial load screws |
