13636661571
Fw |
50 mm |
D |
62 mm |
C |
35 mm |
Cr |
67000 N |
Cor |
132000 N |
Cur |
24300 N |
Reference speed |
5200 rpm |
Limiting speed |
9200 rpm |
r min |
0.6 mm | Minimum chamfer size |
T min |
-20 °C | Minimum operating temperature |
T max |
120 °C | Maximum operating temperature |
