13636661571
d |
100 mm |
D |
180 mm |
B |
34 mm |
Cr |
130000 N |
Cor |
93000 N |
Cur |
5500 N |
Reference speed |
4800 rpm |
Limiting speed |
5000 rpm |
da min |
104.6 mm | Minimum diameter of shaft shoulder |
rmin |
1 mm | Minimum chamfer size |
D1 |
133.2 mm | Inner ring flange diameter |
Da max |
145.4 mm | Maximum diameter of bearing block shoulder |
ra max |
1 mm | Maximum cavity radius |
d1 |
117.6 mm | Shoulder diameter inner ring |
Tmin |
-30 °C | Minimum operating temperature |
Tmax |
150 °C | Maximum operating temperature |
f0 |
16.5 | Calculation coefficient |
