13636661571
d |
25.4 mm |
d(Inch) |
25.4 Inch |
D |
34.925 mm |
B |
4.763 mm |
Cr |
1790 N |
Cor |
1080 N |
Limiting speed |
20000 rpm |
r min |
0.38 mm | Minimum chamfer dimension , |
d 1 |
29 mm | Shoulder diameter inner ring |
D 1 |
31.4 mm | Shoulder diameter outer ring |
T min |
-30 °C | Operating temperature min. |
T max |
120 °C | Operating temperature max. |
