d |
150 mm |
D |
320 mm |
B |
65 mm |
Cr |
330000 N |
Cor |
380000 N |
Cur |
9800 N |
Reference speed |
2900 rpm |
Limiting speed |
3350 rpm |
d a min |
167 mm | Minimum diameter of shaft shoulder |
r min |
4 mm | Minimum chamfer size |
D 1 |
266.2 mm | Inner ring flange diameter |
D a max |
303 mm | Maximum diameter of bearing block shoulder |
r a max |
3 mm | Maximum cavity radius |
d 1 |
205.5 mm | Shoulder diameter inner ring |
T min |
-30 °C | Minimum operating temperature |
T max |
200 °C | Maximum operating temperature |
f 0 |
18 | Calculation coefficient |
