13636661571
d |
65 mm |
D |
140 mm |
B |
33 mm |
Cr |
100000 N |
Cor |
60000 N |
Cur |
4050 N |
Limiting speed |
3050 rpm |
da min |
69.6 mm | Minimum diameter of shaft shoulder |
rmin |
1 mm | Minimum chamfer size |
Da max |
85.4 mm | Maximum diameter of bearing block shoulder |
ra max |
1 mm | Maximum cavity radius |
D2 |
84.2 mm | Inner diameter from recess to outer ring |
d1 |
72.6 mm | Shoulder diameter inner ring |
Tmin |
-20 °C | Minimum operating temperature |
Tmax |
110 °C | Maximum operating temperature |
f0 |
16.6 | Calculation coefficient |
