13636661571
d |
110 mm |
D |
170 mm |
B |
28 mm |
Cr |
85000 N |
Cor |
71000 N |
Cur |
3550 N |
Reference speed |
4850 rpm |
Limiting speed |
5300 rpm |
da min |
117 mm | Minimum diameter of shaft shoulder |
rmin |
2.1 mm | Minimum chamfer size |
D1 |
163.2 mm | Inner ring flange diameter |
Da max |
178 mm | Maximum diameter of bearing block shoulder |
ra max |
2.1 mm | Maximum cavity radius |
d1 |
131.5 mm | Shoulder diameter inner ring |
Tmin |
-30 °C | Minimum operating temperature |
Tmax |
150 °C | Maximum operating temperature |
f0 |
14.4 | Calculation coefficient |
